Color: Matte Black


$ 8999

Product overview

  • Can install up to 9 fans for extreme air cooling.
  • Wide range of liquid cooling compatibility (3x120mm top mount, 2x140 top/front mount, 2x120 front/bottom mount)
  • Fully modular drive cages offer unmatched customization and enable you to only use what you need and keep airflow to a maximum.
  • Fully filtered intake with a large filter for the front intake and two smaller filters for the bottom front and PSU intakes.
  • 34mm of cable management space means that your cables will have an absolutely cavernous place to reside.
  • Discreet SSD mounts help keep your build free from excess wires.
  • Our signature 10-port fan hub allows you to route all your fan cables through the rear of the case, keeping the front nice and tidy.
SizeFull Tower
Model NumberCA-SO530-M1
Drive BaysExternal 5.25" x 3
Internal 3.5" /2.5": 6
Internal 2.5": 1 + 6
Cooling SystemFront 2x140mm/ 120mm or 1x200mm
Rear 1x140mm / 120mm (1x120mm included)
Bottom 2x120mm
Top 2x140mm or 3x120mm (1x120mm included)
Interior 1x120mm/140mm
ClearanceCPU Cooler 183mm
VGA Card 282mm (With Cage & Pivot Fan), 310mm (With Cage), 444mm (Without Cage)
Cable Management 26mm (Lowest Point)/ 34mm (Highest Point)
Dimensions235mm x 507mm x 510.5mm
MaterialSteel, Plastic, Mesh
Motherboard SupportITX, Micro-ATX, ATX, EATX (322x272mm)
Expansion Slots8
External Electronics1 x Audio / Mic
2 x USB 3.0
Product Weight9.2 kg
Warranty2 Years

by Hardware 360Small hw360

For a case that cost below $100 the NZXT Source 530 has it all and then some... more..

by Overclock3DSmall overclock3d

Are we pleased with the Source 530? You bet your buttocks we are. Are we going to give it a Gold? Hell yeah. more..

by El Chapuzas InformaticoSmall elchapuzasinformatico

La NZXT Source 530 encandilará a los amantes de la refrigeración líquida con su excelente capacidad para ventilación y/o radiadores, pero los que buscan un equipo de altas prestaciones con una excelente estética externa también quedarán encantados. more..

by eTeknixSmall eteknix

NZXT have always been listening to what gamers want in their chassis and its great to see that even when they hack a large chunk of the price off their high end models, they don't cut out any of the features that make NZXT cases so great to work with. more..

by Overclock3DSmall overclock3d

Does it represent excellent value for money? Well if you've got this far and haven't worked that out for yourself we aren't going to tell you, well actually we are as value for money award is a bit of a giveaway but you get the point... more..

by 3D Game ManSmall 3dgameman

The NZXT Source 530 Case has a simple, but elegance design. It's much more affordable than other full tower cases on the market... more..

by Hi Tech LegionSmall hitechlegion

The NZXT Source 530 is just such a case, clean lines with minimal flair but maximum efficiency make it a solid choice for entry level builds. NZXT has made the Source 530 a good looking case without tacking on a lot of out of place flair. The Source 530 p more..

by Bit TechSmall bittech

It's easily one of the best cases we've seen for this kind of money for a water-cooled system, and the storage and cooling expansion is exceptional.. more..

by Legit ReviewsSmall legitreviews

he NZXT Source 530 is a great option for people on a budget or just getting into building their own case. If offers features usually only found on higher grade enthusiast level cases. more..

by Pure OverclockSmall pureoverclock

The Source 530 is not only functional in every way, but it also has many features you will not find in a far more expensive full tower case... more..

by TweakTownSmall tweaktown

Considering all that can be done with this chassis, the understated looks externally, and at this price, the Source 530 definitely is in my top five ""bang-for-the-buck"" cases that I have ever tested. more..

by NeoSeekerSmall neoseeker

What you're getting here is an outstanding package that could have been easily priced at more than $100... more..

by Overclocker's Club (OCC)Small overclockersclub

The NZXT Source 530 is an overall great chassis with very few flaws at this price. In fact this is one of the best sub $100 full towers I have come across... more..

by Noticias 3DSmall noticias3d

Estamos ante una caja muy correcta, no le vemos ningún fallo y por lo tanto lo primero es que nos entre por la vista y su diseño sea de nuestro agrado more..

by Hardware LuxxSmall hardwareluxx

Obwohl das NZXT Source 530 für einen Full-Tower sehr günstig verkauft wird, überrascht es mit einer umfangreichen Ausstattung und einer guten Verarbeitungsqualität. more..

by The Mod ZooSmall modzoo

The NZXT Source 530 is very well built, has a ton of features, and can be had for less than a Franklin. more..

by HexusSmall hexus

[The Source 530] is a solid, no-nonsense case that will service most enthusiast builds... more..

by CazuaLLUKSmall caz

[With the Source 530] the world's your oyster, depending how you want your case to look with all the cooling potential. more..

by The PC EnthusiastSmall pcenthus

Whether you are just a newbie system builder or an intermediate one, the Source 530 is capable of accommodating [all] your components. more..

by CazuaLLUKSmall caz

The designers at NZXT did a superb job creating an affordable case that will last you from build to build... more..

CazuaLLUK Video Review

Source 530 ManualPDF9.61 MBDownload


The Source 530 comes ready to accept up to nine fans for maximal airflow and comes equipped with twin 120mm exhaust fans in the top and rear of the case.

Source530 images 01


With large radiators becoming more commonplace, we designed the Source 530 to accept liquid coolers up to 360mm in size. The case also natively supports our line of award-winning CLCs, the Kraken series all-in-one coolers.

Source530 images 02


Fully modular hard drive cages allow builders to choose whether they prioritize cooling or hard drive capacity in any way they want.

Source530 images 03


The Source 530 is filtered using three full coverage, micro-mesh, removable filters keeping hardware clean and temperatures low.

Source530 images 04


Up to 34mm of cable management clearance, a 10-port fan hub, and a discrete SSD mount give you room for a beautifully clean build.

Source530 images 05
